ROBBJACK MHM-602-10 DIA 10MM SH 0.3937 LOC 0.9843 OAL 3.9370 End Mill Standard Flute High Helix Carbide Uncoated Single End Corner Radius 0.0315 0.80MM

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ROBBJACK
SKU: ROBMHM-602-10
Delivery date: 3-5 days
$127.65

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Copy Milling, Profile Milling, Slot Milling, Face Milling, Side Milling
Package Size 1
Shipping State California
Performance Rating High Performance
Made In USA Yes
Dimensional Specifications
Cutter Dia 0.3937 10.00MM
Tool Material Carbide
Machine Side Connection Type Cylindrical
Flutes/Inserts 6
End Of Tool Shape Corner Radius
Cut Rating <65HRC Steel
Single/Double End Single End
Corner Radius 0.0315 0.80MM
Machine Side Connection Size 0.3937 10.00MM
Overall Len 3.9370 100.00MM
Helix Angle 45°
Cutter Style Carbide Bull Nose Finisher
Dimension Description 0.394 x 0.394 x 0.984 x 3.937
Length Type Standard
Inch/Metric Metric
Shank/Pilot Dia 0.3937 10.00MM
Length Of Cut 0.9843 25.00MM
Cutting & Machining Properties
Center Cutting Yes
Coolant Thru No
Cutting Edge Mat Carbide
Industry-Specific Applications
Job Shop Yes
