Picture of RMC MDPNN-85-5DTurning Stick Tool 55.0° Insert Square 1.250 6.000 Oal Left Hand

RMC MDPNN-85-5DTurning Stick Tool 55.0° Insert Square 1.250 6.000 Oal Left Hand

ANSI: MDPNN-85-5D

ISO: MDPNN-85-5D

Need Assistance or Service? Please call 262-251-4020

Manufacturer: RMC
SKU: RMCMDPNN-85-5D
Delivery date: 3-5 days
$183.02
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Made In USA Yes
Application Ext.Turning
Package Size 1
Shipping State Texas
Insert Application General Purpose
Insert Type Negative
Dimensional Specifications
Insert Size Ic 19 "54"
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Clearance Angle 60.0°
Overall Len 6.0000 152.40MM
Lead Angle 62.5°
Tool Width 1.2500
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 1.2500 31.75MM
Cutting & Machining Properties
Insert Style DN
Seat/Nest IDSN-533
Inter/Extern External
Hand R/L Left
Insert Shape/Cutter Pocket Shape 55.0°
Fasteners & Connectors
Seat Screw XNS-510
Lock Pin NL-58
Clamp/Wedge CL-12
