Picture of RMC MDPNN-20-5DTurning Stick Tool 55.0° Insert Square 1.250 6.000 Oal Left Hand

RMC MDPNN-20-5DTurning Stick Tool 55.0° Insert Square 1.250 6.000 Oal Left Hand

ANSI: MDPNN-20-5D

ISO: MDPNN-20-5D

Need Assistance or Service? Please call 262-251-4020

Manufacturer: RMC
SKU: RMCMDPNN-20-5D
Delivery date: 3-5 days
$186.93
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Made In USA Yes
Insert Application General Purpose
Insert Type Negative
Package Size 1
Insert/Tool Tool
Shipping State Texas
Dimensional Specifications
Clearance Angle 60.0°
Overall Len 6.0000 152.40MM
Machine Side Connection Size 1.2500 31.75MM
Lead Angle 62.5°
Insert Size Ic 19 "54"
Tool Material Steel
Machine Side Connection Type Stick Tool
Tool Width 1.2500
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Cutting & Machining Properties
Inter/Extern External
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Seat/Nest IDSN-533
Hand R/L Left
Fasteners & Connectors
Seat Screw XNS-510
Clamp/Wedge CL-12
Lock Pin NL-58
