Picture of RMC MDJNR-24-5DTurning Stick Tool 55.0° Insert Square 1.500 1.440 Oal Right Hand

RMC MDJNR-24-5DTurning Stick Tool 55.0° Insert Square 1.500 1.440 Oal Right Hand

ANSI: MDJNR-24-5D

ISO: MDJNR-24-5D

Need Assistance or Service? Please call 262-251-4020

Manufacturer: RMC
SKU: RMCMDJNR-24-5D
Delivery date: 3-5 days
$186.93
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Shipping State Texas
Made In USA Yes
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Dimensional Specifications
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Clearance Angle 27.0°
Lead Angle 93°
Tool Material Steel
Machine Side Connection Type Stick Tool
Tool Width 1.5000
Insert Size Ic 19 "54"
Overall Len 1.4400 36.58MM
Machine Side Connection Size 1.5000 38.10MM
Cutting & Machining Properties
Hand R/L Right
Insert Shape/Cutter Pocket Shape 55.0°
Seat/Nest IDSN-533
Insert Style DN
Inter/Extern External
Fasteners & Connectors
Seat Screw XNS-510
Lock Pin NL-68
Clamp/Wedge CL-12
