Picture of PARLEC SB62-83T114C Boring Head Finish Boring Head

PARLEC SB62-83T114C Boring Head Finish Boring Head

ANSI: SB62-83T114C

ISO: SB62-83T114C

Need Assistance or Service? Please call 262-251-4020

Manufacturer: PARLEC
SKU: TECSB62-83T114C
Delivery date: 3-5 days
$162.00

Details

Steel Boring Bar .83" Minimum Bore Diameter 5/8" (.625) Shank Diameter with a TPGH 11 Insert Pocket Coolant Through

Modular Boring System Component

Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert/Tool Tool
Shipping State Illinois
Insert Type Positive
Application Mill Boring
Made In USA Yes
Package Size 1
Dimensional Specifications
Tool Material Steel
Insert Size Ic 07 "21"
Machine Side Connection Size 0.6250 15.88MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Machine Side Connection Type Cylindrical
Cutting & Machining Properties
Insert Style TP
Insert Shape/Cutter Pocket Shape Triangle
Cool Sply Type Through
Coolant Thru Yes
