OSG 1615010150 M10-1.50MM Roll Form Mod Bottom 2.5P HSS-CO TiCN

Need Assistance or Service? Please call 262-251-4020

Manufacturer: OSG
SKU: OSG1615010150
Delivery date: 3-5 days
$79.44

Cutting Edge Definition

High speed steel cobalt is a premium grade that offers higher performance compared to traditional high speed steels. Due to increased hardness, these end mills last longer in today's abrasive, heat resistant and exotic materials.

Grade and Coating Description

Titanium Carbo-Nitride (TiCN) has the highest lubricitiy of all the TiN coatings - making it an excellent choice as a dry film lubricant where improved hardness and wear resistance beyond standard Calico TiN is needed. TiCN is normally applied to steels, hardened steel, and stainless steel materials. TiCN is an excellent coating when working against bronze, brass and plastic, therefore, it a good choice for stamping, punching, and forming. Can be stripped and recoated.

Products specifications
Attribute name Attribute value
General Product Information
Application Roll Form Tapping, Blind Hole Tapping, Mod Bottom Tapping, Tapping
Made In USA No
Coating TiCN
Package Size 1
Performance Rating General Performance
Shipping State Illinois
Dimensional Specifications
Thread Type Metric
Length Type Standard
Tap Square 0.2860
Tap Style Roll Form
Cut Rating <42HRC Steel, Stainless Steel
Tap Chamfer 2.5P
Thread Size M10
Dimension Standard ANSI/ANSI
Shank/Pilot Dia 0.3807 9.67MM
Machine Side Connection Type Tap Collet
Drill Range 0.3638 9.24MM - 0.3717 9.44MM
Tap Type Mod Bottom
Thread Pitch 1.50MM
Thread Limit D10
Tool Material Steel
Overall Len 3.9370 100.00MM
Cutting & Machining Properties
Coolant Thru Yes
Cutting Edge Mat HSS-CO
Industry-Specific Applications
Job Shop Yes
