OSG 1413501 No.10-32.00TPI Cut Straight Flute Bottoming 1.5P-2.0P HSS Steam Oxide

Need Assistance or Service? Please call 262-251-4020

Manufacturer: OSG
SKU: OSG1413501
Delivery date: 3-5 days
$11.90

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Grade and Coating Description

The oxide layer produced is porous thereby retaining oil which lowers friction in ferrous applications, thus avoiding the problems of pick-up, cold welding on taps and ‘built-up edge’ on cutting edges.

Products specifications
Attribute name Attribute value
General Product Information
Application Bottom Tapping, Cut Tapping, Tapping, Blind Hole Tapping
Performance Rating High Performance
Package Size 1
Made In USA No
Shipping State Illinois
Coating Steam Oxide
Dimensional Specifications
Drill Range 0.1575 4.00MM - 0.1654 4.20MM
Thread Pitch 32.00TPI
Thread Type NF/UNF/UNEF
Dimension Standard ANSI/ANSI
Cut Rating <30HRC Steel, Aluminum, Ductile Iron, Gray Iron, Stainless Steel
Thread Limit H3/GH3
Shank/Pilot Dia 0.1940 4.93MM
Thread Size No.10
Machine Side Connection Type Tap Collet
Tap Style Cut Straight Flute
Tap Chamfer 1.5P-2.0P
Flute Direction R - Right
Tap Square 0.1510
Length Type Standard
Tap Type Bottoming
Overall Len 2.3750 60.33MM
Flutes/Inserts 3
Tool Material Steel
Cutting & Machining Properties
Cutting Edge Mat HSS
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
