  • NINE 99619-V082-5/8 Flat Blade Indexable Drill Weldon 0.6250 Positive 0.6250 15.88MM - 5/8 Cutter Dia
Picture of NINE 99619-V082-5/8 Flat Blade Indexable Drill Weldon 0.6250 Positive 0.6250 15.88MM - 5/8 Cutter Dia

NINE 99619-V082-5/8 Flat Blade Indexable Drill Weldon 0.6250 Positive 0.6250 15.88MM - 5/8 Cutter Dia

ANSI: 99619-V082-5/8

ISO: 99619-V082-5/8

Need Assistance or Service? Please call 262-251-4020

Manufacturer: NINE
SKU: EVE20424
Delivery date: 3-5 days
$171.68

Features And Benefits

82 degree spotting drill with indexable insert. • Special cutting edge design gives higher precision and position when spotting. • Applications : • Spotting, engraving, grooving and chamfering on milling machines, machining centers. • Spotting, facing on CNC Lathes.

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Package Size 1
Insert/Tool Tool
Application Spot Drilling
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 12
Chamfer Angle 82.0°
Machine Side Connection Size 0.6250 15.88MM
Cutter Dia 0.6250 15.88MM - 5/8
Tool Material Steel
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Machine Side Connection Type Weldon
Overall Len 4.0000 101.60MM
Neck Length 1.1810 30.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Flat Blade
Insert Style V
