Picture of NINE 99616-3/4-142 Indexable Drill End Mill Weldon 0.7500 0.7500 19.05MM - 3/4 Cutter Dia

NINE 99616-3/4-142 Indexable Drill End Mill Weldon 0.7500 0.7500 19.05MM - 3/4 Cutter Dia

ANSI: 99616-3/4-142

ISO: 99616-3/4-142

Need Assistance or Service? Please call 262-251-4020

Manufacturer: NINE
SKU: EVE20376
Delivery date: 3-5 days
$177.74

Features And Benefits

Indexable insert spotting drill holders for 100°/120°/142° spotting. • Reduces spotting time. Increases tool life and position accuracy of the next drilling operation

Products specifications
Attribute name Attribute value
General Product Information
Application Spot Drilling
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Insert Size Ic 11
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Machine Side Connection Type Weldon
Overall Len 4.0000 101.60MM
Depth Of Cut Max 0.1240
Cut Dia Max 0.7280 18.49MM
Cutter Dia 0.7500 19.05MM - 3/4
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Cutting & Machining Properties
Insert Style N9
