  • NINE 99616-13V-5/8 Flat Blade Indexable Drill Weldon 0.6250 Positive 0.6250 15.88MM - 5/8 Cutter Dia
Picture of NINE 99616-13V-5/8 Flat Blade Indexable Drill Weldon 0.6250 Positive 0.6250 15.88MM - 5/8 Cutter Dia

NINE 99616-13V-5/8 Flat Blade Indexable Drill Weldon 0.6250 Positive 0.6250 15.88MM - 5/8 Cutter Dia

ANSI: 99616-13V-5/8

ISO: 99616-13V-5/8

Need Assistance or Service? Please call 262-251-4020

Manufacturer: NINE
SKU: EVE20354
Delivery date: 3-5 days
$171.68

Features And Benefits

60° degree spotting drill with indexable insert. • A single cutting edge creates higher precision and position when spotting. • Applications: • Spotting, engraving, grooving and chamfering on milling machines, machining centers. • Spotting, facing on CNC Lathes

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert/Tool Tool
Insert Application General Purpose
Shipping State Illinois
Insert Type Positive
Application Spot Drilling
Made In USA No
Dimensional Specifications
Chamfer Angle 60.0°
Machine Side Connection Size 0.6250 15.88MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Tool Material Steel
Cutter Dia 0.6250 15.88MM - 5/8
Overall Len 4.0000 101.60MM
Neck Length 1.1810 30.00MM
Machine Side Connection Type Weldon
Insert Size Ic 12
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Flat Blade
Insert Style V
Fasteners & Connectors
Insert Screw NS-35080
