  • NINE 99616-09V Flat Blade Indexable Drill Spot Drill Cylindrical 0.3150 Positive 0.3150 8.00MM Cutter Dia
Picture of NINE 99616-09V Flat Blade Indexable Drill Spot Drill Cylindrical 0.3150 Positive 0.3150 8.00MM Cutter Dia

NINE 99616-09V Flat Blade Indexable Drill Spot Drill Cylindrical 0.3150 Positive 0.3150 8.00MM Cutter Dia

ANSI: 99616-09V

ISO: 99616-09V

Need Assistance or Service? Please call 262-251-4020

Manufacturer: NINE
SKU: EVE20348
Delivery date: 3-5 days
$171.68

Features And Benefits

60° degree spotting drill with indexable insert. • A single cutting edge creates higher precision and position when spotting. • Applications: • Spotting, engraving, grooving and chamfering on milling machines, machining centers. • Spotting, facing on CNC Lathes

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Package Size 1
Application Spot Drilling
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Chamfer Angle 60.0°
Cutter Dia 0.3150 8.00MM
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.3150 8.00MM
Insert Size Ic 8
Tool Material Steel
Overall Len 2.3620 59.99MM
Shank/Pilot Dia 0.3150 8.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Flat Blade
Inter/Extern External
Insert Style V
Fasteners & Connectors
Insert Screw NS-25045
