M.A. FORD 16578740 DIA 20MM SH 0.7874 LOC 0.9843 OAL 2.9921 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Ball Nose TuffCut® GP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: M.A. FORD
SKU: MAF16571
Delivery date: 3-5 days
$203.60

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Ball Slot Milling, Side Milling, Copy Milling, Ball Milling, Profile Milling
Made In USA Yes
Performance Rating General Performance
Shipping State Iowa
Package Size 1
Dimensional Specifications
Dimension Description 0.787 x 0.787 x 0.984 x 2.992
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Shank/Pilot Dia 0.7874 20.00MM
Cutter Dia 0.7874 20.00MM
Flutes/Inserts 4
Length Type Standard
Inch/Metric Metric
Machine Side Connection Size 0.7874 20.00MM
Overall Len 2.9921 76.00MM
Length Of Cut 0.9843 25.00MM
Helix Angle 30°
Tool Material Carbide
Machine Side Connection Type Cylindrical
End Of Tool Shape Ball Nose
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Center Cutting Yes
Industry-Specific Applications
Job Shop Yes
