M.A. FORD 16570870 DIA 18MM SH 0.7087 LOC 0.9843 OAL 2.9921 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Ball Nose TuffCut® GP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: M.A. FORD
SKU: MAF16567
Delivery date: 3-5 days
$146.71

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Ball Milling, Ball Slot Milling, Profile Milling, Copy Milling
Made In USA Yes
Package Size 1
Shipping State Iowa
Performance Rating General Performance
Dimensional Specifications
End Of Tool Shape Ball Nose
Flutes/Inserts 4
Length Type Standard
Overall Len 2.9921 76.00MM
Length Of Cut 0.9843 25.00MM
Helix Angle 30°
Dimension Description 0.709 x 0.709 x 0.984 x 2.992
Machine Side Connection Type Cylindrical
Shank/Pilot Dia 0.7087 18.00MM
Inch/Metric Metric
Machine Side Connection Size 0.7087 18.00MM
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Cutter Dia 0.7087 18.00MM
Tool Material Carbide
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Center Cutting Yes
Industry-Specific Applications
Job Shop Yes
