M.A. FORD 16531500 DIA 8MM SH 0.3150 LOC 0.5118 OAL 2.0079 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Ball Nose TuffCut® GP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: M.A. FORD
SKU: MAF16545
Delivery date: 3-5 days
$26.85

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Copy Milling, Ball Milling, Ball Slot Milling, Profile Milling
Made In USA Yes
Performance Rating General Performance
Package Size 1
Shipping State Iowa
Dimensional Specifications
Dimension Description 0.315 x 0.315 x 0.512 x 2.008
Overall Len 2.0079 51.00MM
Helix Angle 30°
Machine Side Connection Size 0.3150 8.00MM
Flutes/Inserts 4
Length Of Cut 0.5118 13.00MM
Length Type Standard
Cutter Dia 0.3150 8.00MM
Inch/Metric Metric
Single/Double End Single End
End Of Tool Shape Ball Nose
Tool Material Carbide
Machine Side Connection Type Cylindrical
Shank/Pilot Dia 0.3150 8.00MM
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Cutter Style Carbide Ball Finisher
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Center Cutting Yes
Industry-Specific Applications
Job Shop Yes
