M.A. FORD 16521650 DIA 5.50MM SH 0.2362 LOC 0.4724 OAL 2.007 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Ball Nose TuffCut® GP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: M.A. FORD
SKU: MAF16533
Delivery date: 3-5 days
$24.99

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Ball Milling, Copy Milling, Ball Slot Milling, Profile Milling, Side Milling
Shipping State Iowa
Performance Rating General Performance
Package Size 1
Made In USA Yes
Dimensional Specifications
Machine Side Connection Size 0.2362 6.00MM
Tool Material Carbide
Dimension Description 0.217 x 0.236 x 0.472 x 2.008
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Cutter Dia 0.2165 5.50MM
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Inch/Metric Metric
Machine Side Connection Type Cylindrical
Shank/Pilot Dia 0.2362 6.00MM
End Of Tool Shape Ball Nose
Overall Len 2.0079 51.00MM
Helix Angle 30°
Flutes/Inserts 4
Length Of Cut 0.4724 12.00MM
Length Type Standard
Cutting & Machining Properties
Center Cutting Yes
Coolant Thru No
Cutting Edge Mat Carbide
Industry-Specific Applications
Job Shop Yes
