Picture of M.A. Ford 16621650 Dia 5.50mm SH 0.2362 LOC 0.4724 OAL2.007 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Ball NoseBall TuffCut® GP

M.A. Ford 16621650 Dia 5.50mm SH 0.2362 LOC 0.4724 OAL2.007 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Ball NoseBall TuffCut® GP

Part Number: MAF16633 0.217 x 0.236 x 0.472 x 2.008

Need Assistance or Service? Please call 262-251-4020

Manufacturer: M.A. FORD
SKU: 1242342
Vendor: Sussex Tool and Supply
Call (262) 251-4020 for pricing
M.A. FORD 16621650 Standard Helix End Mill Carbide Uncoated Ball Nose Ball Standard Flute Flutes 2 Single End TuffCut® GP Carbide
Products specifications
Attribute name Attribute value
Shipping State Iowa
Made In USA YES
Cutter Type Solid End Mill
Tool Material Carbide
Cutting Edge Mat Carbide
Machine Side Connection Type Cylindrical
Cut Rating Stainless Steel, Gray Iron, Ductile Iron, <42HRC Steel
Mach Side Connection Size 0.2362 6.00MM
Overall Length 2.0079 51.00MM
Coolant Thru Non Coolant
Shank/Pilot Dia 0.2362 6.00MM
Flutes/Inserts 2
Tool Dia 0.2165 5.50MM
Length Type STANDARD
Performance Rating General Performance
Length Of Cut 0.4724 12.00MM
End Of Tool Shape Ball Nose
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Inch/Metric Metric
Helix Angle 30
Center Cutting Center Cutting
