Picture of LMT FETTE MDJNR 16-4D DFC Turning Stick Tool 55.0° 1.000 Tool

LMT FETTE MDJNR 16-4D DFC Turning Stick Tool 55.0° 1.000 Tool

ANSI: MDJNR 16-4D DFC

ISO: MDJNR 16-4D DFC

Need Assistance or Service? Please call 262-251-4020

Manufacturer: LMT FETTE
SKU: LMT53671
Delivery date: 3-5 days
Call (262) 251-4020 for pricing
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Insert/Tool Tool
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Overall Len 6.0000 152.40MM
Lead Angle 93°
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 27.0°
Insert Size Ic 12 "43"
Cutting & Machining Properties
Hand R/L Right
Coolant Thru Yes
Seat/Nest IDSN433
Inter/Extern External
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Fasteners & Connectors
Lock Pin NL46
