Picture of LMT FETTE EMU90 A17 . 100SEI Milling 90.0°, End Mill Milling Cutter 1.500 Cutter Diameter

LMT FETTE EMU90 A17 . 100SEI Milling 90.0°, End Mill Milling Cutter 1.500 Cutter Diameter

ANSI: EMU90 A17 . 100SEI

ISO: EMU90 A17 . 100SEI

Need Assistance or Service? Please call 262-251-4020

Manufacturer: LMT FETTE
SKU: LMT1950303
Delivery date: 3-5 days
$438.01
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Application Pocket Milling, Ramp Milling, Side Milling, Face Milling, Slot Milling
Shipping State Illinois
Insert Type Positive
Package Size 1
Dimensional Specifications
Machine Side Connection Type Screw On
Flutes/Inserts 2
Corner Radius 0.1200 3.05MM
Tool Material Steel
Depth Of Cut Max 0.5900
Machine Side Connection Size M16
Cutter Dia 1.5000 38.10MM - 1-1/2
Overall Len 1.9700 50.04MM
Insert Size Ic 11 "21"
Cutting & Machining Properties
Insert Style VC
Insert Shape/Cutter Pocket Shape 35.0°
