Picture of KYOCERA MFH0625W625032T3 Feed Mill 0.625 Diameter 0.625 Shank 3.196 OAL 2 Flute

KYOCERA MFH0625W625032T3 Feed Mill 0.625 Diameter 0.625 Shank 3.196 OAL 2 Flute

ANSI: MFH0625W625032T3

ISO: MFH0625W625032T3

Need Assistance or Service? Please call 262-251-4020

Manufacturer: KYOCERA
SKU: KYO8607058
Delivery date: 3-5 days
Call (262) 251-4020 for pricing
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application General Purpose
Shipping State Illinois
Application Ramp Milling, Slot Milling, Face Milling, Copy Milling, Feed Milling
Insert Type Negative
Made In USA No
Package Size 1
Dimensional Specifications
Neck Length 1.2500 31.75MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Tool Material Steel
Cutter Dia 0.6250 15.88MM - 5/8
Overall Len 3.1960 81.18MM
Insert Size Ic 3
Flutes/Inserts 2
Machine Side Connection Size 0.6250 15.88MM
Cut Dia Min 0.3100 7.87MM
Machine Side Connection Type Cylindrical
Cutting & Machining Properties
Insert Style LO
Insert Shape/Cutter Pocket Shape Barbell
