  • K-Tool SDCS-90 90° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.430 Cutter Diameter 0.375 Round
Picture of K-Tool SDCS-90 90° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.430 Cutter Diameter 0.375 Round

K-Tool SDCS-90 90° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.430 Cutter Diameter 0.375 Round

ANSI: SDCS-90

ISO: SDCS-90

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: KTOSDCS-90
Delivery date: 3-5 days
$143.83

Features And Benefits

90° Spot Drills - 2 Flutes Effective - Must be held in a Collet

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Shipping State Pennsylvania
Made In USA Yes
Application Spot Drilling
Package Size 1
Insert Application General Purpose
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Cylindrical
Cut Dia Min 0.0700 1.78MM - #50
Overall Len 3.2500 82.55MM
Machine Side Connection Size 0.3750 9.53MM
Cutter Dia 0.4300 10.92MM
Cut Dia Max 0.3900 9.91MM
Shank/Pilot Dia 0.3750 9.53MM - 3/8
Cutting & Machining Properties
Insert Style 90
Inter/Extern External
Fasteners & Connectors
Clamp Screw 25618
Clamp/Wedge 180310
