  • K-Tool SDCS-823 82° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.500 Cutter Diameter 1.000 Round
Picture of K-Tool SDCS-823 82° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.500 Cutter Diameter 1.000 Round

K-Tool SDCS-823 82° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.500 Cutter Diameter 1.000 Round

ANSI: SDCS-823

ISO: SDCS-823

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: KTOSDCS-823
Delivery date: 3-5 days
$215.29

Features And Benefits

82° Spot Drills - 2 Flutes Effective - Must be held in a Collet

Products specifications
Attribute name Attribute value
General Product Information
Application Spot Drilling
Insert Application General Purpose
Shipping State Pennsylvania
Insert/Tool Tool
Package Size 1
Made In USA Yes
Dimensional Specifications
Cutter Dia 1.5000 38.10MM - 1-1/2
Cut Dia Max 1.5000 38.10MM - 1-1/2
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Tool Material Steel
Insert Size Ic 823
Overall Len 4.9370 125.40MM
Cut Dia Min 0.2500 6.35MM - 1/4 - E
Shank/Pilot Dia 1.0000 25.40MM
Cutting & Machining Properties
Insert Style SD
Fasteners & Connectors
Clamp Screw 103212
Clamp/Wedge 621915
