Picture of K-Tool SDCS-820 82° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.625 Cutter Diameter 0.500 Round

K-Tool SDCS-820 82° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 0.625 Cutter Diameter 0.500 Round

ANSI: SDCS-820

ISO: SDCS-820

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: KTOSDCS-820
Delivery date: 3-5 days
$143.83

Features And Benefits

82° Spot Drills - 2 Flutes Effective - Must be held in a Collet

Products specifications
Attribute name Attribute value
General Product Information
Made In USA Yes
Insert Application General Purpose
Package Size 1
Insert/Tool Tool
Shipping State Pennsylvania
Application Spot Drilling
Dimensional Specifications
Cut Dia Max 0.4000 10.16MM
Cutter Dia 0.6250 15.88MM - 5/8
Insert Size Ic 820
Cut Dia Min 0.0930 2.36MM
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Tool Material Steel
Machine Side Connection Size 0.5000 12.70MM
Overall Len 3.2500 82.55MM
Machine Side Connection Type Cylindrical
Cutting & Machining Properties
Insert Style SD
Fasteners & Connectors
Clamp/Wedge 311205
Clamp Screw 44025
