  • K-Tool SDCS-142-500 142° Spot Drill - Split Point Design 2 Flutes Effective - Split point design for reduced cutting pressure - Designed for spotting along shoulders - Must be held in a Collet Milling Cutter 0.500 Cutter Diameter 0.500 Round
Picture of K-Tool SDCS-142-500 142° Spot Drill - Split Point Design 2 Flutes Effective - Split point design for reduced cutting pressure - Designed for spotting along shoulders - Must be held in a Collet Milling Cutter 0.500 Cutter Diameter 0.500 Round

K-Tool SDCS-142-500 142° Spot Drill - Split Point Design 2 Flutes Effective - Split point design for reduced cutting pressure - Designed for spotting along shoulders - Must be held in a Collet Milling Cutter 0.500 Cutter Diameter 0.500 Round

ANSI: SDCS-142-500

ISO: SDCS-142-500

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: KTOSDCS-142-500
Delivery date: 3-5 days
$139.36

Features And Benefits

142° Spot Drills - Split Point Design 2 Flutes Effective - Split point design for reduced cutting pressure - Designed for spotting along shoulders - Must be held in a Collet

Products specifications
Attribute name Attribute value
General Product Information
Application Spot Drilling
Insert/Tool Tool
Shipping State Pennsylvania
Insert Application General Purpose
Package Size 1
Made In USA Yes
Dimensional Specifications
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.5000 12.70MM
Cut Dia Max 0.5000 12.70MM - 1/2
Tool Material Steel
Cutter Dia 0.5000 12.70MM - 1/2
Cut Dia Min 0.0930 2.36MM
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Overall Len 4.0000 101.60MM
Cutting & Machining Properties
Insert Style SD
Fasteners & Connectors
Clamp/Wedge 251207
Clamp Screw 325B
