  • K-Tool SDCS-1002L 100° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.125 Cutter Diameter 1.000 Round
Picture of K-Tool SDCS-1002L 100° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.125 Cutter Diameter 1.000 Round

K-Tool SDCS-1002L 100° Spot Drill - 2 Flutes Effective - Must be held in a Collet Milling Cutter 1.125 Cutter Diameter 1.000 Round

ANSI: SDCS-1002L

ISO: SDCS-1002L

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: KTOSDCS-1002L
Delivery date: 3-5 days
$198.32

Features And Benefits

100° Spot Drills - 2 Flutes Effective - Must be held in a Collet

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Application Spot Drilling
Made In USA Yes
Insert Application General Purpose
Shipping State Pennsylvania
Insert/Tool Tool
Dimensional Specifications
Cut Dia Min 0.2500 6.35MM - 1/4 - E
Cutter Dia 1.1250 28.58MM - 1-1/8
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Tool Material Steel
Cut Dia Max 1.0300 26.16MM
Overall Len 6.5000 165.10MM
Shank/Pilot Dia 1.0000 25.40MM
Cutting & Machining Properties
Insert Style 1002
Fasteners & Connectors
Clamp Screw 103212
Clamp/Wedge 621915
