Picture of K-Tool RM-1500A-4 Milling Cutter 90.0° 1.500 Cutter Diameter 1.000 Weldon

K-Tool RM-1500A-4 Milling Cutter 90.0° 1.500 Cutter Diameter 1.000 Weldon

ANSI: RM-1500A-4

ISO: RM-1500A-4

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: KTORM-1500A-4
Delivery date: 3-5 days
$224.23
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Package Size 1
Insert/Tool Tool
Shipping State Pennsylvania
Application Side Milling, Face Milling
Made In USA Yes
Insert Type Positive
Dimensional Specifications
Flutes/Inserts 4
Depth Of Cut Max 0.5400
Tool Material Steel
Neck Length 0.8750 22.23MM
Machine Side Connection Type Weldon
Overall Len 4.0000 101.60MM
Cutter Dia 1.5000 38.10MM - 1-1/2
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style MG
Fasteners & Connectors
Insert Screw 560T
