K-Tool DT-6250 Milling Cutter 45.0° 0.625 Cutter Diameter 0.500 Weldon

ANSI: DT-6250

ISO: DT-6250

Need Assistance or Service? Please call 262-251-4020

Manufacturer: K-TOOL
SKU: KTODT-6250
Delivery date: 3-5 days
$95.59

Features And Benefits

45° Dovetail Cutters

Products specifications
Attribute name Attribute value
General Product Information
Insert Application Finishing, Semi Finishing
Insert Type Positive
Application Dovetail Milling
Insert/Tool Tool
Shipping State Pennsylvania
Made In USA Yes
Package Size 1
Dimensional Specifications
Insert Size Ic 15
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Cutter Dia 0.6250 15.88MM - 5/8
Neck Dia 0.3120
Machine Side Connection Size 0.5000 12.70MM
Overall Len 2.5000 63.50MM
Depth Of Cut Max 0.1700
Cut Dia Max 0.6250 15.88MM - 5/8
Tool Material Steel
Neck Length 0.7500 19.05MM
Machine Side Connection Type Weldon
Flutes/Inserts 2
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Form
Insert Style DT
Fasteners & Connectors
Insert Screw 164T
