  • ISCAR TR6 ER D25/0.98-3-M12-10 Milling Cutter 45.0°, 90.0° 0.984 Diameter Screw On T10 1.850 OAL 3 Flute
Picture of ISCAR TR6 ER D25/0.98-3-M12-10 Milling Cutter 45.0°, 90.0° 0.984 Diameter Screw On T10 1.850 OAL 3 Flute

ISCAR TR6 ER D25/0.98-3-M12-10 Milling Cutter 45.0°, 90.0° 0.984 Diameter Screw On T10 1.850 OAL 3 Flute

ANSI: TR6 ER D25/0.98-3-M12-10

ISO: TR6 ER D25/0.98-3-M12-10

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3346857
Delivery date: 3-5 days
$326.40

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Face Milling, Feed Milling, Round Milling, Chamfering, Side Milling
Shipping State Texas
Insert Application Roughing, Semi Finishing
Package Size 1
Made In USA No
Insert/Tool Tool
Dimensional Specifications
Overall Len 1.8500 46.99MM
Machine Side Connection Size T10
Cutter Dia 0.9840 24.99MM
Machine Side Connection Type Screw On
Cut Dia Max 0.9840 24.99MM
Depth Of Cut Max 0.0590
Cut Dia Min 0.7870 19.99MM
Flutes/Inserts 3
Insert Size Ic 10
Tool Material Steel
Cutting & Machining Properties
Insert Style TR
Cool Sply Type External
Coolant Thru No
Insert Shape/Cutter Pocket Shape Multi
Fasteners & Connectors
Insert Screw 7006951
