  • ISCAR TR6 ER D16/0.63-2-M08-07 Milling Cutter 45.0°, 90.0° 0.630 Diameter Screw On M08 1.661 OAL 2 Flute
Picture of ISCAR TR6 ER D16/0.63-2-M08-07 Milling Cutter 45.0°, 90.0° 0.630 Diameter Screw On M08 1.661 OAL 2 Flute

ISCAR TR6 ER D16/0.63-2-M08-07 Milling Cutter 45.0°, 90.0° 0.630 Diameter Screw On M08 1.661 OAL 2 Flute

ANSI: TR6 ER D16/0.63-2-M08-07

ISO: TR6 ER D16/0.63-2-M08-07

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3320744
Delivery date: 3-5 days
$287.04

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Application Round Milling, Side Milling, Feed Milling, Chamfering, Face Milling
Shipping State Texas
Made In USA No
Insert/Tool Tool
Insert Type Positive
Package Size 1
Dimensional Specifications
Cut Dia Min 0.5510 14.00MM
Cutter Dia 0.6300 16.00MM
Flutes/Inserts 2
Cut Dia Max 0.6300 16.00MM
Insert Size Ic 7
Machine Side Connection Size M08
Machine Side Connection Type Screw On
Tool Material Steel
Overall Len 1.6610 42.19MM
Depth Of Cut Max 0.0390
Cutting & Machining Properties
Insert Style TR
Coolant Thru No
Cool Sply Type External
Insert Shape/Cutter Pocket Shape Multi
Fasteners & Connectors
Insert Screw 7006042
