Picture of ISCAR TGTL 25.4-4-IQ-2Z Cut Off,Grooving Stick Tool 1.000 Tool

ISCAR TGTL 25.4-4-IQ-2Z Cut Off,Grooving Stick Tool 1.000 Tool

ANSI: TGTL 25.4-4-IQ-2Z

ISO: TGTL 25.4-4-IQ-2Z

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC2302885
Delivery date: 3-5 days
$201.60

Details

Integral shank 2 pocket tools with a very rigid clamping. Enables machining at very high feed rates and provides excellent straightness and surface finish. Recommended for parting interrupted cuts. Excellent tool and pocket life.

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert Application General Purpose
Made In USA No
Insert Type Positive
Insert/Tool Tool
Application Ext.Grooving, Parting
Shipping State Texas
Dimensional Specifications
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Overall Len 5.9050 149.99MM
Insert Size Ic 4
Tool Material Steel
Machine Side Connection Type Stick Tool
Cutting Width 0.1460 3.71MM
Tool Width 1.0000
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape L Shape
Inter/Extern External
Hand R/L Left
Insert Style TA
