  • ISCAR T490 FLN D4.0-06-1.5-16* Milling Cutter 90.0° 4.000 Diameter Face Mill 1.500 2.000 OAL 6 Flute
Picture of ISCAR T490 FLN D4.0-06-1.5-16* Milling Cutter 90.0° 4.000 Diameter Face Mill 1.500 2.000 OAL 6 Flute

ISCAR T490 FLN D4.0-06-1.5-16* Milling Cutter 90.0° 4.000 Diameter Face Mill 1.500 2.000 OAL 6 Flute

ANSI: T490 FLN D4.0-06-1.5-16*

ISO: T490 FLN D4.0-06-1.5-16*

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3105216
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Semi Finishing, Roughing
Shipping State Texas
Insert Type Negative
Made In USA No
Application Face Milling, Side Milling, Slot Milling
Package Size 1
Dimensional Specifications
Cutter Dia 4.0000 101.60MM
Tool Material Steel
Overall Len 2.0000 50.80MM
Insert Size Ic 16
Flutes/Inserts 6
Depth Of Cut Max 0.6300
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Max 4.0000 101.60MM
Machine Side Connection Size 1.5000 38.10MM
Cut Dia Min 4.0000 101.60MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Style LN
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Other
Fasteners & Connectors
Insert Screw 7000219
