Picture of ISCAR T490 ELN D.62-2-W.62-08C Milling Cutter 90.0° 0.625 Diameter Weldon 0.625 3.250 OAL 2 Flute

ISCAR T490 ELN D.62-2-W.62-08C Milling Cutter 90.0° 0.625 Diameter Weldon 0.625 3.250 OAL 2 Flute

ANSI: T490 ELN D.62-2-W.62-08C

ISO: T490 ELN D.62-2-W.62-08C

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3105501
Delivery date: 3-5 days
$357.12

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Side Milling, Slot Milling, Face Milling
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Package Size 1
Shipping State Texas
Dimensional Specifications
Cut Dia Min 0.6250 15.88MM - 5/8
Cut Dia Max 0.6250 15.88MM - 5/8
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Cutter Dia 0.6250 15.88MM - 5/8
Machine Side Connection Type Weldon
Insert Size Ic 8
Tool Material Steel
Depth Of Cut Max 0.3150
Flutes/Inserts 2
Machine Side Connection Size 0.6250 15.88MM
Overall Len 3.2500 82.55MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Other
Insert Style LN
Cool Sply Type Through Hole
Max Ramp Angle 2.00°
Fasteners & Connectors
Insert Screw 4305676
