Picture of ISCAR T290 ELN D.62-04-C.62-05 Milling Cutter 90.0° 0.625 Diameter Round 0.625 3.110 OAL 4 Flute

ISCAR T290 ELN D.62-04-C.62-05 Milling Cutter 90.0° 0.625 Diameter Round 0.625 3.110 OAL 4 Flute

ANSI: T290 ELN D.62-04-C.62-05

ISO: T290 ELN D.62-04-C.62-05

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3105239
Delivery date: 3-5 days
$379.20

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Face Milling, Side Milling, Slot Milling
Package Size 1
Insert Application Semi Finishing, Roughing
Shipping State Texas
Insert/Tool Tool
Made In USA No
Insert Type Positive
Dimensional Specifications
Machine Side Connection Size 0.6250 15.88MM
Insert Size Ic 5
Cut Dia Max 0.6250 15.88MM - 5/8
Tool Material Steel
Machine Side Connection Type Cylindrical
Cutter Dia 0.6250 15.88MM - 5/8
Depth Of Cut Max 0.1970
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Flutes/Inserts 4
Cut Dia Min 0.6250 15.88MM - 5/8
Overall Len 3.1100 78.99MM
Cutting & Machining Properties
Insert Style LN
Insert Shape/Cutter Pocket Shape Other
Coolant Thru Yes
Cool Sply Type Through Hole
Fasteners & Connectors
Insert Screw 7000229
