Picture of ISCAR T290 ELN D.38-02-C.38-05 Milling Cutter 90.0° 0.375 Diameter Round 0.375 3.000 OAL 2 Flute

ISCAR T290 ELN D.38-02-C.38-05 Milling Cutter 90.0° 0.375 Diameter Round 0.375 3.000 OAL 2 Flute

ANSI: T290 ELN D.38-02-C.38-05

ISO: T290 ELN D.38-02-C.38-05

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3105150
Delivery date: 3-5 days
$310.08

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Slot Milling, Side Milling, Face Milling
Insert Application Roughing, Semi Finishing
Made In USA No
Shipping State Texas
Insert/Tool Tool
Package Size 1
Dimensional Specifications
Flutes/Inserts 2
Cut Dia Max 0.3750 9.53MM - 3/8
Overall Len 3.0000 76.20MM
Machine Side Connection Type Cylindrical
Cut Dia Min 0.3750 9.53MM - 3/8
Shank/Pilot Dia 0.3750 9.53MM - 3/8
Insert Size Ic 5
Depth Of Cut Max 0.1970
Tool Material Steel
Machine Side Connection Size 0.3750 9.53MM
Cutter Dia 0.3750 9.53MM - 3/8
Cutting & Machining Properties
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Other
Insert Style LN
Coolant Thru Yes
Inter/Extern External
Fasteners & Connectors
Insert Screw 7066668
