  • ISCAR SOF45 D4.0-09-1.50-R18 Milling Cutter 45.0°, 44.0° 4.000 Diameter Face Mill 1.500 2.190 OAL 9 Flute
Picture of ISCAR SOF45 D4.0-09-1.50-R18 Milling Cutter 45.0°, 44.0° 4.000 Diameter Face Mill 1.500 2.190 OAL 9 Flute

ISCAR SOF45 D4.0-09-1.50-R18 Milling Cutter 45.0°, 44.0° 4.000 Diameter Face Mill 1.500 2.190 OAL 9 Flute

ANSI: SOF45 D4.0-09-1.50-R18

ISO: SOF45 D4.0-09-1.50-R18

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3107315
Delivery date: 3-5 days
$1,171.20

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Finishing, Roughing
Shipping State Texas
Application Face Milling
Package Size 1
Insert/Tool Tool
Insert Type Negative
Made In USA No
Dimensional Specifications
Insert Size Ic 07, 18
Cutter Dia 4.0000 101.60MM
Cut Dia Min 4.0000 101.60MM
Machine Side Connection Size 1.5000 38.10MM
Depth Of Cut Max 0.1970
Tool Material Steel
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Max 4.6700 118.62MM
Overall Len 2.1900 55.63MM
Flutes/Inserts 9
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Multi
Coolant Thru Yes
Insert Style ON,SN
Cool Sply Type Through Hole
Fasteners & Connectors
Insert Screw 7007136
