  • ISCAR SOF45 D2.0-04-0.75-R18 Milling Cutter 45.0°, 44.0° 2.000 Diameter Face Mill 0.750 1.940 OAL 4 Flute
Picture of ISCAR SOF45 D2.0-04-0.75-R18 Milling Cutter 45.0°, 44.0° 2.000 Diameter Face Mill 0.750 1.940 OAL 4 Flute

ISCAR SOF45 D2.0-04-0.75-R18 Milling Cutter 45.0°, 44.0° 2.000 Diameter Face Mill 0.750 1.940 OAL 4 Flute

ANSI: SOF45 D2.0-04-0.75-R18

ISO: SOF45 D2.0-04-0.75-R18

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3181262
Delivery date: 3-5 days
$566.40

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Semi Finishing, Roughing, Finishing
Package Size 1
Shipping State Texas
Application Face Milling
Insert Type Negative
Made In USA No
Dimensional Specifications
Depth Of Cut Max 0.1970
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Insert Size Ic 07, 18
Cut Dia Max 2.6700 67.82MM
Flutes/Inserts 4
Cutter Dia 2.0000 50.80MM
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Min 2.0000 50.80MM
Overall Len 1.9400 49.28MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Multi
Insert Style ON,SN
Cool Sply Type Through Hole
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 7007136
