  • ISCAR SOF45 8/16-D2.0-06-0.75R Milling Cutter 45.0° 2.000 Diameter Face Mill 0.750 1.301 OAL 6 Flute
Picture of ISCAR SOF45 8/16-D2.0-06-0.75R Milling Cutter 45.0° 2.000 Diameter Face Mill 0.750 1.301 OAL 6 Flute

ISCAR SOF45 8/16-D2.0-06-0.75R Milling Cutter 45.0° 2.000 Diameter Face Mill 0.750 1.301 OAL 6 Flute

ANSI: SOF45 8/16-D2.0-06-0.75R

ISO: SOF45 8/16-D2.0-06-0.75R

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3104603
Delivery date: 3-5 days
$631.68

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Semi Finishing, Roughing
Application Feed Milling, Face Milling, Round Milling
Shipping State Texas
Insert Type Negative
Made In USA No
Package Size 1
Dimensional Specifications
Cut Dia Min 2.0000 50.80MM
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Depth Of Cut Max 0.6420
Cutter Dia 2.0000 50.80MM
Flutes/Inserts 6
Overall Len 1.3010 33.05MM
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Max 2.4090 61.19MM
Cutting & Machining Properties
Insert Style SN,ON,RX,RN
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Multi
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 7000219
