  • ISCAR SD S-A-L3.50-C.500-SP11 SH 0.50 OAL 3.6510 Replacable Head Acc. 89° Conical Steel Single End T-Slot
Picture of ISCAR SD S-A-L3.50-C.500-SP11 SH 0.50 OAL 3.6510 Replacable Head Acc. 89° Conical Steel Single End T-Slot

ISCAR SD S-A-L3.50-C.500-SP11 SH 0.50 OAL 3.6510 Replacable Head Acc. 89° Conical Steel Single End T-Slot

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3110808
Delivery date: 3-5 days
$120.00

Cutting Edge Definition

Tool steel is any of various carbon steels and alloy steels that are particularly well-suited to be made into tools and tooling, including cutting tools, dies, hand tools, knives, and others.

Products specifications
Attribute name Attribute value
General Product Information
Application Dovetail Milling, Copy Milling, Feed Milling, Side Milling, Face Milling, Circle Segment, Groove Milling, Profile Milling, Slot Milling
Made In USA No
Performance Rating High Performance
Shipping State Texas
Package Size 1
Dimensional Specifications
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Length Type Standard
Machine Side Connection Type Cylindrical
Overall Len 3.6510 92.74MM
Inch/Metric Inch
Cutter Style Screw On Shanks
Single/Double End Single End
Machine Side Connection Size 0.5000 12.70MM
Cutting & Machining Properties
Center Cutting No
Cutting Edge Mat Steel
Coolant Thru No
Industry-Specific Applications
Agricultural YES
Medical Yes
Energy Yes
Aerospace Yes
Automotive Yes
Job Shop Yes
Mold Yes
