Picture of ISCAR PH D2.50-H055-A-W1.50-13 Milling Cutter 2.500 Diameter Weldon 1.500 6.310 OAL 6 Flute

ISCAR PH D2.50-H055-A-W1.50-13 Milling Cutter 2.500 Diameter Weldon 1.500 6.310 OAL 6 Flute

ANSI: PH D2.50-H055-A-W1.50-13

ISO: PH D2.50-H055-A-W1.50-13

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3102911
Delivery date: 3-5 days
$824.64

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Shipping State Texas
Application Plunge Milling
Package Size 1
Insert/Tool Tool
Insert Type Negative
Made In USA No
Dimensional Specifications
Cut Dia Min 2.5000 63.50MM - 2-1/2
Flutes/Inserts 6
Insert Size Ic 13
Depth Of Cut Max 1.4150
Machine Side Connection Size 1.5000 38.10MM
Cutter Dia 2.5000 63.50MM - 2-1/2
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Tool Material Steel
Overall Len 6.3100 160.27MM
Machine Side Connection Type Weldon
Cutting & Machining Properties
Insert Style PL
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Rectagonal
Cool Sply Type Through Hole
Fasteners & Connectors
Insert Screw 7002024
