Picture of ISCAR PH D2.00-H040-W1.25-13 Milling Cutter 2.000 Diameter Weldon 1.250 4.430 OAL 4 Flute

ISCAR PH D2.00-H040-W1.25-13 Milling Cutter 2.000 Diameter Weldon 1.250 4.430 OAL 4 Flute

ANSI: PH D2.00-H040-W1.25-13

ISO: PH D2.00-H040-W1.25-13

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3181177
Delivery date: 3-5 days
$630.72

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Shipping State Texas
Application Plunge Milling
Package Size 1
Insert/Tool Tool
Insert Type Negative
Made In USA No
Dimensional Specifications
Cutter Dia 2.0000 50.80MM
Machine Side Connection Type Weldon
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Insert Size Ic 13
Overall Len 4.4300 112.52MM
Tool Material Steel
Machine Side Connection Size 1.2500 31.75MM
Depth Of Cut Max 0.3030
Flutes/Inserts 4
Cut Dia Min 2.0000 50.80MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Style PL
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Rectagonal
Fasteners & Connectors
Insert Screw 7003603
