  • ISCAR P290 FPW D2.00-5-.75-18 Milling Cutter 90.0° 2.000 Diameter Face Mill 0.750 1.570 OAL 5 Flute
Picture of ISCAR P290 FPW D2.00-5-.75-18 Milling Cutter 90.0° 2.000 Diameter Face Mill 0.750 1.570 OAL 5 Flute

ISCAR P290 FPW D2.00-5-.75-18 Milling Cutter 90.0° 2.000 Diameter Face Mill 0.750 1.570 OAL 5 Flute

ANSI: P290 FPW D2.00-5-.75-18

ISO: P290 FPW D2.00-5-.75-18

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3110786
Delivery date: 3-5 days
$560.64

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Type Positive
Application Face Milling, Side Milling, Slot Milling
Insert Application Roughing, Semi Finishing
Package Size 1
Shipping State Texas
Made In USA No
Dimensional Specifications
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Flutes/Inserts 5
Cutter Dia 2.0000 50.80MM
Cut Dia Max 2.0000 50.80MM
Depth Of Cut Max 0.7080
Cut Dia Min 2.0000 50.80MM
Insert Size Ic 18
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Other
Coolant Thru Yes
Insert Style AC
Cool Sply Type Through Hole
Fasteners & Connectors
Insert Screw 7000402
Only registered users can write reviews
