  • ISCAR IQ845 FSYD2.5-05-1.00-R07 Milling Cutter 45.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 5 Flute
Picture of ISCAR IQ845 FSYD2.5-05-1.00-R07 Milling Cutter 45.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 5 Flute

ISCAR IQ845 FSYD2.5-05-1.00-R07 Milling Cutter 45.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 5 Flute

ANSI: IQ845 FSYD2.5-05-1.00-R07

ISO: IQ845 FSYD2.5-05-1.00-R07

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3106547
Delivery date: 3-5 days
$674.88

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Finishing, Roughing
Shipping State Texas
Insert/Tool Tool
Application Face Milling
Insert Type Negative
Made In USA No
Package Size 1
Dimensional Specifications
Insert Size Ic 7
Cut Dia Min 2.5000 63.50MM - 2-1/2
Cut Dia Max 2.8700 72.90MM
Machine Side Connection Size 1.0000 25.40MM
Tool Material Steel
Flutes/Inserts 5
Overall Len 1.7500 44.45MM
Depth Of Cut Max 0.1810
Machine Side Connection Type Face Mill/Shell Mill
Cutter Dia 2.5000 63.50MM - 2-1/2
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Insert Style SY
Cool Sply Type Through Hole
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 7006097
