Picture of ISCAR HTP D20-3-M10-LN06 Milling Cutter 0.787 Diameter Screw On M10 1.181 OAL 3 Flute

ISCAR HTP D20-3-M10-LN06 Milling Cutter 0.787 Diameter Screw On M10 1.181 OAL 3 Flute

ANSI: HTP D20-3-M10-LN06

ISO: HTP D20-3-M10-LN06

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3106099
Delivery date: 3-5 days
$441.60

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Plunge Milling
Package Size 1
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Shipping State Texas
Dimensional Specifications
Machine Side Connection Size M10
Flutes/Inserts 3
Cutter Dia 0.7870 19.99MM
Cut Dia Min 0.7870 19.99MM
Machine Side Connection Type Screw On
Insert Size Ic 6
Overall Len 1.1810 30.00MM
Depth Of Cut Max 0.1970
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Rectagonal
Cool Sply Type Through Hole
Insert Style LN
Fasteners & Connectors
Insert Screw 7006242
