Picture of ISCAR HP E90AN-D.50-2-W.50-7 Milling Cutter 90.0° 0.500 Diameter Weldon 0.500 3.500 OAL 2 Flute

ISCAR HP E90AN-D.50-2-W.50-7 Milling Cutter 90.0° 0.500 Diameter Weldon 0.500 3.500 OAL 2 Flute

ANSI: HP E90AN-D.50-2-W.50-7

ISO: HP E90AN-D.50-2-W.50-7

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3103894
Delivery date: 3-5 days
$273.60

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Slot Milling, Face Milling, Pocket Milling, Side Milling
Insert Type Positive
Insert Application Roughing, Semi Finishing
Package Size 1
Made In USA No
Insert/Tool Tool
Shipping State Texas
Dimensional Specifications
Cut Dia Max 0.5000 12.70MM - 1/2
Machine Side Connection Size 0.5000 12.70MM
Insert Size Ic 7
Flutes/Inserts 2
Depth Of Cut Max 0.3030
Cutter Dia 0.5000 12.70MM - 1/2
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Overall Len 3.5000 88.90MM
Cut Dia Min 0.5000 12.70MM - 1/2
Tool Material Steel
Machine Side Connection Type Weldon
Cutting & Machining Properties
Max Ramp Angle 2.70°
Cool Sply Type External
Coolant Thru No
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
Fasteners & Connectors
Insert Screw 7003603
