Picture of ISCAR HOF D2.00-04-0.75-R06 Milling Cutter 42.0° 2.000 Diameter Face Mill 0.750 1.770 OAL 4 Flute

ISCAR HOF D2.00-04-0.75-R06 Milling Cutter 42.0° 2.000 Diameter Face Mill 0.750 1.770 OAL 4 Flute

ANSI: HOF D2.00-04-0.75-R06

ISO: HOF D2.00-04-0.75-R06

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3181230
Delivery date: 3-5 days
$502.08

Details

FACE MILL HOLDS ROUND, OCTAGONAL AND SQUARE IN SAME CUTTER. GREAT FOR JOB SHOP, VERY FREE CUTTING.

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Face Milling, Round Milling
Insert/Tool Tool
Made In USA No
Insert Application Roughing, Semi Finishing
Package Size 1
Shipping State Texas
Dimensional Specifications
Cutter Dia 2.0000 50.80MM
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Insert Size Ic 76
Overall Len 1.7700 44.96MM
Cut Dia Max 2.3700 60.20MM
Machine Side Connection Type Face Mill/Shell Mill
Depth Of Cut Max 0.2160
Cut Dia Min 2.0000 50.80MM
Flutes/Inserts 4
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Multi
Insert Style RE,OE,SE
Cool Sply Type Through Hole
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 7006316
