Picture of ISCAR HM90 F90AP D1.25-3-.50 Milling Cutter 90.0° 1.250 Diameter Face Mill 0.500 1.378 OAL 3 Flute

ISCAR HM90 F90AP D1.25-3-.50 Milling Cutter 90.0° 1.250 Diameter Face Mill 0.500 1.378 OAL 3 Flute

ANSI: HM90 F90AP D1.25-3-.50

ISO: HM90 F90AP D1.25-3-.50

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3102076
Delivery date: 3-5 days
$418.56

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Shipping State Texas
Insert Type Positive
Application Face Milling, Ramp Milling, Slot Milling, Pocket Milling, Side Milling
Package Size 1
Insert/Tool Tool
Made In USA No
Insert Application Roughing, Semi Finishing
Dimensional Specifications
Cutter Dia 1.2500 31.75MM - 1-1/4
Machine Side Connection Size 0.5000 12.70MM
Insert Size Ic 10
Depth Of Cut Max 0.1900
Tool Material Steel
Machine Side Connection Type Face Mill/Shell Mill
Overall Len 1.3780 35.00MM
Flutes/Inserts 3
Cut Dia Max 1.2500 31.75MM - 1-1/4
Cut Dia Min 1.2500 31.75MM - 1-1/4
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Cool Sply Type External
Insert Style AP
Coolant Thru No
Fasteners & Connectors
Insert Screw 7002441
