Picture of ISCAR HM90 EAL-D150-C125L8-16BR Milling Cutter 90.0° 1.500 Diameter Round 1.250 8.000 OAL 2 Flute

ISCAR HM90 EAL-D150-C125L8-16BR Milling Cutter 90.0° 1.500 Diameter Round 1.250 8.000 OAL 2 Flute

ANSI: HM90 EAL-D150-C125L8-16BR

ISO: HM90 EAL-D150-C125L8-16BR

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3181171
Delivery date: 3-5 days
$631.68

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Application Ramp Milling, Side Milling, Pocket Milling, Face Milling, Slot Milling
Insert/Tool Tool
Insert Application Semi Finishing, Roughing
Shipping State Texas
Insert Type Positive
Made In USA No
Dimensional Specifications
Flutes/Inserts 2
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Tool Material Steel
Machine Side Connection Size 1.2500 31.75MM
Machine Side Connection Type Weldon
Cut Dia Min 1.5000 38.10MM - 1-1/2
Overall Len 8.0000 203.20MM
Insert Size Ic 16
Depth Of Cut Max 0.6100
Cutter Dia 1.5000 38.10MM - 1-1/2
Cut Dia Max 1.5000 38.10MM - 1-1/2
Cutting & Machining Properties
Insert Style AL
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Max Ramp Angle 17.00°
Cool Sply Type Through Hole
Fasteners & Connectors
Insert Screw 7002377
