  • ISCAR HM390 FTP D2.50-7-1.0-10 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.770 OAL 7 Flute
Picture of ISCAR HM390 FTP D2.50-7-1.0-10 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.770 OAL 7 Flute

ISCAR HM390 FTP D2.50-7-1.0-10 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.770 OAL 7 Flute

ANSI: HM390 FTP D2.50-7-1.0-10

ISO: HM390 FTP D2.50-7-1.0-10

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3106639
Delivery date: 3-5 days
$743.04

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Pocket Milling, Face Milling, Slot Milling, Ramp Milling, Side Milling
Insert Type Positive
Package Size 1
Insert Application Semi Finishing, Roughing
Shipping State Texas
Made In USA No
Dimensional Specifications
Tool Material Steel
Cut Dia Min 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 1.0000 25.40MM
Depth Of Cut Max 0.3150
Flutes/Inserts 7
Insert Size Ic 10
Cutter Dia 2.5000 63.50MM - 2-1/2
Overall Len 1.7700 44.96MM
Cut Dia Max 2.5000 63.50MM - 2-1/2
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Style TP
Insert Shape/Cutter Pocket Shape Triangle
Coolant Thru Yes
Cool Sply Type Through Hole
Fasteners & Connectors
Insert Screw 7000219
