Picture of ISCAR HGAIL 25-3T9 Face Grooving Adapter Blade Tool

ISCAR HGAIL 25-3T9 Face Grooving Adapter Blade Tool

ANSI: HGAIL 25-3T9

ISO: HGAIL 25-3T9

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC2550095
Delivery date: 3-5 days
$244.80

Important Notes

HGN & GRIP 3.. inserts can be used only with right-hand adapters, HGPL 3.. inserts with left-hand adapters.

Details

Adapters for internal face grooving and turning. Dmin .472".

Face Grooving Face Grooving & Turning Int. Face Grooving Int. Face Recessing

Products specifications
Attribute name Attribute value
General Product Information
Shipping State Texas
Insert Type Positive
Package Size 1
Insert/Tool Tool
Application Face Grooving
Insert Application General Purpose
Made In USA No
Dimensional Specifications
Face Groove Max Dia 1.3400
Machine Side Connection Type Modular
Overall Len 2.1650 54.99MM
Insert Size Ic 3
Tool Material Steel
Face Groove Min Dia 0.9800
Cutting Width 0.1180 3.00MM
Depth Of Cut Max 0.3540
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Other
Insert Style GR,HG
Hand R/L Left
