Picture of ISCAR HFAIL 75C-4T30DG Face Grooving Adapter Blade Tool

ISCAR HFAIL 75C-4T30DG Face Grooving Adapter Blade Tool

ANSI: HFAIL 75C-4T30DG

ISO: HFAIL 75C-4T30DG

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC2500726
Delivery date: 3-5 days
$244.80

Details

Adapters for internal face grooving and turning. Dmin 2.16".

Face Grooving Face Grooving & Turning Int. Face Grooving Int. Face Recessing

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Insert Application General Purpose
Made In USA No
Shipping State Texas
Insert/Tool Tool
Application Face Grooving
Package Size 1
Dimensional Specifications
Machine Side Connection Type Modular
Face Groove Max Dia 5.5100
Cutting Width 0.1570 3.99MM
Depth Of Cut Max 1.1810
Insert Size Ic 4
Face Groove Min Dia 2.9500
Tool Material Steel
Overall Len 2.6970 68.50MM
Cutting & Machining Properties
Insert Style DG,HF,HG
Insert Shape/Cutter Pocket Shape Dog Bone
Hand R/L Left
