Picture of ISCAR HFAIL 70C-6T28DG Face Grooving Adapter Blade Tool

ISCAR HFAIL 70C-6T28DG Face Grooving Adapter Blade Tool

ANSI: HFAIL 70C-6T28DG

ISO: HFAIL 70C-6T28DG

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC2550027
Delivery date: 3-5 days
$244.80

Details

Adapters for internal face grooving and turning. Dmin 2.16".

Face Grooving Face Grooving & Turning Int. Face Grooving Int. Face Recessing

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Made In USA No
Insert Application General Purpose
Application Face Grooving
Insert/Tool Tool
Shipping State Texas
Insert Type Positive
Dimensional Specifications
Insert Size Ic 6
Cutting Width 0.2360 5.99MM
Face Groove Max Dia 3.9400
Tool Material Steel
Face Groove Min Dia 2.7600
Depth Of Cut Max 1.1020
Overall Len 2.7170 69.01MM
Machine Side Connection Type Modular
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Dog Bone
Hand R/L Left
Insert Style HF,HG
